Vendor: TENSE

3-phase digital panel multimeter DIN current, voltage, and frequency indicator

Barcode: EM-250DIN
€69,16
€69,16
12 in stock
Mark: 250A
  • Description
  • User Manual
  • Payment methods
  • Warranty

TENSE 3-fazni večfunkcijski panelni multimeter

Opis

Digitalni 3-fazni multimeter TENSE je večnamenski panelni merilnik, namenjen spremljanju električnih parametrov v 3-faznih sistemih. Instrument prikazuje napetost, tok in frekvenco ter omogoča spremljanje posameznih faz.

Multimeter je zasnovan za montažo na standardno 35-milimetrsko tirnico DIN.

Glavne prednosti

  • Večnamensko merjenje 4 veličin:

    • Tok (I)

    • napetosti (U) - L-L in L-N

    • frekvenca (Hz)

  • Enofazno spremljanje

  • Natančno merjenje s tokovnim transformatorjem

  • Vključen merilni transformator pri modelih EM-100DIN in EM-250DIN

  • Enostavna montaža na standardno DIN-lestvico

Tehnične specifikacije

ParameterVrednost
Območje merjenja tokaEM-06DIN: 5/5 ... 9995/5 A (posredno merjenje) EM-100DIN: 1 - 100 A EM-250DIN: 2 - 250 A
Območje merjenja napetostiL-N: 1 - 300 V AC L-L: 1 - 500 V AC
Frekvenca40 - 60 Hz
Namestitev35 mm DIN-lestvica
UporabaIndustrijska in domača 3-fazna omrežja


Priporočila

  • Za natančno merjenje toka priporočamo uporabo združljivih tokovnih transformatorjev:
    60/5, 75/5, 100/5, 150/5, 200/5, 250/5, 300/5, 400/5, 500/5, 600/5, 800/5, 1000/5, 1500/5

  • Transformatorje lahko kupite neposredno v naši e-trgovini.
